How a query runs

Every statement sent to POST /api/v1/clusters/:id/query passes the same seven stages, in order. A stage that can’t decide refuses.

What the analyzer refuses

The guard walks the full syntax tree, so a write hidden in a CTE, a subquery, a set operation or EXPLAIN ANALYZE is classified as a write.

Unparsable SQL, more than one statement, or input over 1 MiB is refused outright. If the analyzer itself fails, that is a deny too.

Full list: security model and architecture.

Access & approvals

An organization holds projects, and projects hold clusters. Access is granted per project, covering all its clusters, or per cluster.

Grants can carry an expires_at, for just-in-time access. A scoped admin can’t grant to themselves, and can’t delegate access that outlasts their own.

Four-eyes approvals

Safety policy

Each cluster has one policy. New clusters get the defaults for their environment, and cluster admins change them in the console or with PUT /clusters/:id/policy.

Two limits are fixed rather than configurable: results stop at 32 MiB, and approvals expire after 24 hours.

Masking and blocked tables

masked_columns takes patterns such as email, users.ssn and *.password*. They match returned column names, including table-qualified patterns when the query references that table, and apply to DML RETURNING too, even inside data-modifying CTEs. Masked values stay masked in copies and CSV or JSON exports, and exports escape spreadsheet formulas.

blocked_tables takes table, schema.table, schema.* and *.table, matched case-insensitively.

Performance suggestions

Alongside the verdict, the analyzer suggests faster or safer forms of a query. Suggestions are advisory: they never change the verdict or the SQL that runs, and the server never runs a fix itself.

Deploy

One binary with the console embedded. Nodes are stateless; everything lives in a PostgreSQL metadata store.

1. Quick start with demo databases

git clone https://github.com/djkeshawa/visp-db-access
cd visp-db-access
export VDA_MASTER_KEY="$(openssl rand -base64 32)"
export VDA_BOOTSTRAP_ADMIN_PASSWORD='choose-a-long-random-password'
docker compose --profile demo up --build

Open http://localhost:8080 and sign in as admin@example.com. The admin password needs at least 12 characters, and the server refuses to start without a valid 32-byte key. Register the demo databases in the development environment, since production defaults block writes:

To try the console with no backend at all, run it in mock mode: cd web && npm ci && npm run dev:mock, then sign in as admin@visp.dev with demo-password.

2. Docker and Helm

Each release publishes an image to GHCR and a Linux x86_64 binary on GitHub Releases. The image is distroless and runs as non-root on port 8080.

docker pull ghcr.io/djkeshawa/visp-db-access:0.1.0

The Helm chart in deploy/helm/visp-db-access runs two replicas with a Service, a pod disruption budget, and an optional TLS Ingress and autoscaler. Pods run as UID 65532 with a read-only root filesystem and every capability dropped.

kubectl create secret generic vda-secrets \
  --from-literal=database-url='postgres://…' \
  --from-literal=master-key="$(openssl rand -base64 32)"
helm upgrade --install vda deploy/helm/visp-db-access \
  --set existingSecret=vda-secrets

The secret needs database-url and master-key. Readiness is /readyz and liveness /healthz.

3. Configuration

Every setting is an environment variable with a matching command-line flag. .env files are not loaded.

visp-db-access serve          # the default: apply migrations, then serve
visp-db-access migrate        # apply metadata migrations only
visp-db-access gen-key        # print a new master key
VDA_ADMIN_PASSWORD=… visp-db-access create-admin --email you@example.com --name "Your Name"

4. Operations

Health

/healthz returns 200 while the process runs; /readyz returns 503 when the metadata store is unreachable. One elected node probes every cluster every 30 seconds, and health history is kept for 7 days.

Metrics

/metrics exports Prometheus request counters, query durations, blocked queries and pool gauges, behind the same network gate as the API. Protect it with VDA_METRICS_TOKEN or at your ingress.

Backups

Back up the master key together with the metadata database. If the key is lost, re-enter each cluster’s password in its settings.

Upgrades

Migrations run at startup under an advisory lock, so replicas don’t race. Before 1.0, minor releases may change the API and storage schema, and only the latest release is supported.

Each node keeps up to five connections per database endpoint, so budget target connections across replicas. Shutdown is graceful: active queries are cancelled and history drains first.

Full reference: deployment and development.

AWS discovery

Find RDS and Aurora databases across accounts and regions, then import the ones you choose. Discovery only reads, and stores no AWS keys.

The gateway uses the AWS SDK’s default credentials: IRSA, an ECS task role, an instance profile or environment variables. Attach deploy/aws/iam-policy.json, which allows only rds:DescribeDBInstances and rds:DescribeDBClusters.

1. For another account, create a role there from deploy/aws/cross-account-role.json, naming the gateway’s role as principal and an external ID unique to this gateway, and attach the discovery policy.
2. Allow the gateway to call sts:AssumeRole on that exact role ARN.
3. Add a source under Settings → Cloud discovery with the role ARN, external ID and up to 20 regions, then select Test.
4. Import under Clusters → Discovered: choose a project and environment and enter credentials. TLS defaults to verify_full.

Sources rescan every 60 minutes by default (5–1,440). Aurora clusters use the writer endpoint, plus the reader endpoint when there are readers, and RDS read replicas attach to their source. A region that fails to scan never marks its databases as gone.

Drift is flagged as endpoint_changed, replica_changed, engine_changed or deleted. Sync applies a new host, port or replica; a changed endpoint needs the password again, and engine changes and deletions wait for manual review.

Full reference: AWS discovery.

HTTP API

The console uses the same versioned API under /api/v1. Bodies are snake_case JSON, IDs are UUIDs and timestamps are UTC.

Sign in with POST /auth/login, which sets the HttpOnly vda_session cookie. Every mutating request must send X-Requested-With: vda. There are no user API tokens in 0.1. Errors look like {"error": {"code", "message", "details"}}.

The full contract: API.md.

Security model & known limits

The gateway is one layer. Database privileges remain the primary control: give it the least-privileged database role that fits each cluster.

Credentials

AES-256-GCM, bound to the cluster’s ID and write-only. Changing any endpoint field needs the password again, so a stored password can’t be pointed at a new host.

Sign-in

Argon2id password hashes. Ten failed sign-ins lock the email for 15 minutes across all IPs, and a locked account gets the same 401 as a wrong password.

Targets

Addresses are checked when a pool is created and at every health check. Cloud metadata, link-local and zero-network addresses are always blocked; loopback needs VDA_ALLOW_PRIVATE_TARGETS.

Audit

Query intent and final status are written synchronously. Other audit events go through a bounded queue and can be lost in a crash.

Known limits

• Concurrency limits, cancellation and login throttling are per node.
• The guard doesn’t resolve search paths, read user-defined function bodies or estimate plans.
• Masking can be bypassed with aliases and computed expressions.
• MySQL’s max_execution_time covers only SELECT; writes rely on the client deadline and lock timeouts. Rollback needs transactional storage such as InnoDB, MySQL DDL commits implicitly, and a connection lost during COMMIT leaves the outcome uncertain.
• DNS rebinding: a DNS change between validation and connection remains a risk. Enforce outbound firewall rules too.
• A history row left running by a crash becomes unknown, which implies neither success nor rollback.
• No SSO yet: users sign in with email and password.

On the roadmap: RDS IAM authentication, GCP and Azure discovery, OIDC/SAML SSO and SCIM, group grants, just-in-time access requests, saved queries, distributed cancellation, durable audit delivery and SIEM export, MongoDB and SQL Server, and SSH tunnels.

Report vulnerabilities privately through GitHub’s private reporting. Full model: SECURITY-MODEL.md.

When something is stuck

The server won’t start: the master key is missing or invalid

Set VDA_MASTER_KEY to a standard base64, 32-byte key from openssl rand -base64 32 or visp-db-access gen-key.

Stored credentials can’t be decrypted

The key changed. Restore the original key, or re-enter each cluster’s password.

Writes are blocked in the demo

The cluster is registered as production. Use the development environment.

409 approval_required

Select Request approval and give a reason. Someone else with admin on the cluster reviews it.

422 query_denied or cost_exceeded

The response lists the issue codes. For cost, narrow the query or ask an admin to raise max_cost.

429 busy

The cluster’s concurrency slots on this node are full. Wait and retry; writes are never retried automatically.

A loopback database is rejected in development

Set VDA_ALLOW_PRIVATE_TARGETS=true.

Cancel doesn’t stop the query

The request reached another node. Turn on load-balancer affinity.

Source, issues and changelog: github.com/djkeshawa/visp-db-access. Checked against release 0.1.0 on October 11, 2026.
